Zeb ETS8M
₹
1,299
Product Description
8 x 10/100 Mbps LAN Ports | Auto Negotiation | Auto MDI/MDIX | High Speed 10/100Mbps | IEEE 802.3X flow control | Compact Design | Fanless | Plug & Play | Wide Compatibility | Full Wire Speed
Specifications
| Connector Type | 8 100M RJ45 Ports | |
| Network Protocols | IEEE802.3/802.3u, IEEE802.3i, IEEE802.3x | |
| Network Media | 10BASE-T: <100 meters100BASE-TX: <100 meters | |
| Power Supply | Input: DC 5V⎓2A | |
| Performance Specification |
Bandwidth: 1.6GbpsMAC: 1KPacket Buffer Memory: 768Kbits10M Packet Forwarding Rate: 14880pps/port100M Packet Forwarding Rate: 148800pps/port |
|
| LED Indicator | Power (Red): ON - Powering, OFF - No Power Ethernet (Green) : Flashing - Data Transmission, OFF - Disconnect | |
| Working Environment | Operating Temperature: 0°C ~ 40°CStorage Temperature: -40°C ~ 70°COperating Humidity: 5% ~ 90% (No Condensation)Storage Humidity: 5% ~ 90% (No Condensation) | |
| Physical Parameter | Product Dimension W x D x H : 13 x 7.8 x 2.3cmPackage Dimension: W x D x H : Net. Weight: 111g | |
| Port Surge Protection | 1KV | |
| Lightning Protection | 1KV | |
| Forwarding Mode | Store and forward | |
| Country of Origin | People's republic of china | |
| Package Contents | ||
| Ethernet Switch | 1 U | |
| Power Adapter | 1 U | |
| QR Code Guide | 1 U |
