Zeb 24PG2UG2UF 300 - 24 Port POE Switch
₹
31,999
Product Description
24 Self Adaptive PoE Ports | Dual Gigabit Uplink Ports | 250m Extended Transmission (Max.) | 300W Output (Max.) | Upto 30W Per Port | Full Duplex | High Data Rate | Wide Compatibility | Dynamic Power Control | Short Circuit Protection | Anti Interference Capability | Lightning Protection | Dual SFP Port | AI Watchdog Function | Mounting Kit
Specifications
| Connector Type | 24 Ports 10/100/1000M PoE + 2 Ports 1000M Ethernet Uplink + 2 Port 1000M SFP | |
| Network Protocols | IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab | |
| PoE Parameters | PoE Standard: IEEE802.3af/at (15.4W) & IEEE802.3at (30W) PoE Compatibility: IEEE802.3af/at Self AdaptivePower Pin Assignment : MODE A [1/2(+), 3/6(-)] | |
| Network Media | 10BASE-T: Cat 6 UTP (=<250 Meters)100BASE-TX: Cat6 UTP (=<100 Meters) | |
| Power Supply | Input: AC100-240V, 50/60Hz Output: 30W Per Port Power Budget: 300W | |
| Performance Specification | Bandwidth: 56GbpsMAC: 8KPacket Buffer Memory: 4Mbits10M Packet Forwarding Rate: 14880 pps/port100M Packet Forwarding Rate: 148800 pps/port1000M Packet Forwarding Rate: 1488000 pps/port | |
| LED Indicator | Power (Red): Lit - Powered, Unlit - No Power Ethernet(Green) : Flash - Data Transmit, Unlit - Disconnect | |
| Working Environment | Operating Temperature: 10°C ~ 55°CStorage Temperature: 20°C ~ 70°COperating Humidity: Max 20 ~ 95% (Non-condensation)Storage Humidity: Max 20 ~ 95% (Non-condensation) | |
| Physical Parameter | Product Dimension (W x D x H) : 44 x 19.5 x 4.5 cmPackage Dimension: (W x D x H) : Net. Weight: 2.2 Kg | |
| Transmission Distance | Data Transmission Distance: 250 (Max.)PoE distance upto 250 meters with 10M via Cat.6 | |
| Port Surge Protection | 6KV | |
| Forwarding Mode | Store and forward | |
| Country of Origin | PRC | |
| Package Contents | ||
| Ethernet Switch | 1 U | |
| Power Cord | 1 U | |
| QR Code Guide | 1 U | |
| Mounting Kit | 1 Set |
