Zeb 8PM2UG1UF 120 - 8 Port POE Switch
₹
4,999
Product Description
8 Self Adaptive PoE Ports | Dual Gigabit Uplink Ports | SFP Port | AI Watchdog Function | 120W Output (Max.) | High Data Rate | Upto 30W Per Port | Wide Compatibility | Short Circuit Protection | Anti Interference Capability | Lightning & Surge Protection | Dynamic Power Control
Specifications
| Connector Type | 8 Ports 100M PoE + 2 Ports 1000M Ethernet Uplink + 1 x 1000M SFP | |
| Network Protocols | IEEE802.3/802.3u, IEEE802.3x, IEEE802.3ab | |
| PoE Parameters | PoE Standard: IEEE802.3af (15.4W) & IEEE802.3at (30W) PoE Compatibility: IEEE802.3af/at Self AdaptivePower Pin Assignment : MODE A [1/2(+), 3/6(-)] | |
| Network Media | 10BASE-T: <250 meters100BASE-TX: <100 meters | |
| Power Supply | Input: AC100-240V, 50/60Hz Output: 30W Per Port Power Budget: 120W | |
| Performance Specification | Bandwidth: 2 GbpsMAC: 1KPacket Buffer Memory: 1Mbits10M Packet Forwarding Rate: 14880pps/port100M Packet Forwarding Rate: 148800pps/port | |
| LED Indicator | Power (Red): Lit - Powered, Unlit - No Power Ethernet (Green) : Flash - Data Transmit, Unlit - Disconnect | |
| Working Environment | Operating Temperature: -10°C ~ 55°CStorage Temperature: -20°C ~ 70°COperating Humidity: Max 20 ~ 95% (Non-condensation)Storage Humidity: Max 20 ~ 95% (Non-condensation) | |
| Physical Parameter | Product Dimension (W x D x H) : 19 x 12.5 x 3.8 cmPackage Dimension: (W x D x H) : 20 x 19.6 x 4.8 cmNet. Weight: 595g | |
| Transmission Distance | Data Transmission Distance: 250 (Max.)PoE distance upto 250 meters with 10M via Cat.6 | |
| Port Surge Protection | 6KV | |
| Forwarding Mode | Store and forward | |
| Country of Origin | PRC | |
| Package Contents | ||
| Ethernet Switch | 1 U | |
| Power Cord | 1 U | |
| QR Code Guide | 1 U |
