Zeb-OU1KE6

CAPACITY	1000 VA / 800 W
INPUT
Voltage Range
Low Line Transfer	160VAC/140VAC/120VAC/110VAC±5% (Ambient Temp.<35°C) (based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
Low Line comeback	175VAC/155VAC/135VAC/125VAC ± 5 % (Ambient Temp.<35°C) (based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
High Line Transfer	280 VAC ± 5 %
High Line Comeback	270 VAC ± 5 %
Frequency Range	40Hz ~ 70 Hz
Phase	Single phase with ground
Power Factor	≥0.99 @ nominal voltage (input voltage)
OUTPUT
Output voltage	200/208/220/230/240VAC
AC Voltage Regulation	±1% (Batt. Mode)
Frequency Range	47 ~ 53 Hz or 57 ~ 63 Hz (Synchronized Range)
Frequency Range (Batt. Mode)	50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz
Overload	Ambient Temp <35°C) 105%~110%: UPS shuts down after 10 minutes at battery mode or transfer to bypass when the utility is normal. 110%~130%: UPS shuts down after 1minute at battery mode or transfer to bypass when the utility is normal. >130%:UPS shuts down after 3seconds at battery mode or transfer to bypass when the utility is normal.
Current Crest Ratio	3:1
Harmonic Distortion	≤ 3 % THD (linear load); = 6 % THD (non-linear load)
Transfer Time	AC Mode to Batt. Mode : Zero Inverter to Bypass : 4 ms (Typical)
Waveform (Batt. Mode)	Pure Sinewave
EFFICIENCY
AC Mode	88%
Battery Mode	83%
BATTERY
Numbers	3*
Recharge Time	Depending On The Capacity Of External Batteries
Charging Current	1.0A/2.0A/4.0A/6.0A
Charging Voltage	41.0 VDC ±1%
PHYSICAL
Dimension	282 x 145 x 220mm (D x W x H )
Net. Weight	4.1 kg
ENVIRONMENT
Operation Humidity	20-90 % RH @ 0- 40°C (non-condensing)
Noise Level	Less than 50dBA @ 1 Meter
MANAGEMENT
Smart RS-232 or USB	Supports Windows® XP/Vista/7/8/10, Linux, Unix and MAC
