Zeb C3C1XAB-OD2-180M-PRIME

	Model Name	ZEB-C3C1XAB-OD2-180M-PRIME
	Length of the cable	180M
	Inner cable (Single strand core) Material	SOLID COPPER
	Inner cable (Single strand core) Gauge as per AWG	24 AWG
	Inner cable (Single strand core) dia in mm	0.500MM±0.02mm
	Inner cable (Single strand core) Resistance per meter	≈ 0.086 Ω/m
	Sleeve Conductor Material /COAXIAL BRAIDING	aluminium alloy
	Sleeve Conductor Resistance per meter	≈ 0.079 Ω/m
	Shielding Used (Material)/ IN COAXIAL VIDEO	al. mylar tape
	Gauge of the combined strands of the 3 cores
	Red	≈ 0.0871 sqmm
	Black	≈ 0.0871 sqmm
	Yellow	≈0.0871 sqmm
	No. of strands of the 3 cores
	Red	14
	Black	14
	Yellow	14
	Diameter of a single strand in the 3 cores
	Red	0.089mm±0.005mm
	Black	0.089mm±0.005mm
	Yellow	0.089mm±0.005mm
	Resistance per meter in the 3 cores
	Red	≈ 0.193 Ω/m
	Black	≈ 0.193 Ω/m
	Yellow	≈ 0.193 Ω/m
	Loop Resistance one power core 100 m	≈ 39Ω
	Capacitance Between Inner & Outer Conductor of coaxial	≈ 65-70 pF/m
	Operation temperature	-5°C to 65°C
	Storage Temperature	-10°C to 65°C
	Insulation material (power cores)	LDPE
	Inner Insulation Jacket/ sheath	PVC
	Outer Insulation Jacket/sheath	LDPE
	Package Contents
	Cable	180 Meter x 1 U
