Zeb B75M2 - LGA 1155 Socket

₹ 5,149

Supported CPU	Socket 1155 / Intel Pentium / Celeron / i3 / i5 / i7 (2nd & 3rd Generation) Series Processors
Chipset	Intel B75 Chipset
Memory Supported	2nos DDR3 Dual channel RAM slots Memory up to 16GB Supports DDR3 1066/1333/1600MHz memory
BIOS	AMI BIOS
I/O Interface	1 x HDMI port, 1 x VGA Port, 4 x USB 2.0 Port, 2 x USB 3.0 Port, 1 x RJ45 Port, 1 x 3-in-1 Audio
Onboard Interface	1 x 24 pin ATX Power Connector, 1 x 4 Pin ATX 12V Power Connector, 3 x SATA II, 1 x SATA III, 1 x USB 2.0 Header, 1 x USB 3.0 Header, 1 x Front Audio Connector, 1 x Front Panel Connector, 1 x Speaker Connector, 2 x Fan Connectors, 1 x clear CMOS header, 1 x PCIe 16 x Slot, 1 x Debug Card Header, 1 x M.2 slot
Integrated Sound	With 5.1-Channel HD Audio
Integrated LAN	Supports RTL8106E 10/100 Mbps Ethernet LAN
Expansion Slot	1 x PCI Express 2.0 x16 size slot
Form Factor	Micro-ATX
Country of Origin	People's Republic of China
Package contents
ZEB-B75M2 Motherboard	1 U
SATA Cable	1 U
I/O Backplate	1 U
Driver Disc	1 U
User Manual	1 U
